Bayview Collection
Bayview Wood Shaker
Birch plywood box construction with solid wood shaker doors and dovetail rubberwood drawers, fully assembled and ready to install.
The Bayview Wood Shaker is built on a 1/2" birch plywood box with a natural birch interior and a 3/4" x 1-1/2" solid birch face frame. Doors feature a solid wood frame with an MDF center panel in a clean shaker profile with squared edges and full overlay. Adjustable 3/4" plywood shelves and a natural sides exterior complete the cabinet.
Drawer boxes are constructed from 5/8" rubberwood with dovetail joinery at all four corners, providing lasting structural integrity under daily load. Soft-close, concealed door hinges are 6-way adjustable for precise alignment after installation. Undermount full-extension drawer glides bring each drawer to full access without side clearance loss.
Sample Available
See and feel the quality for yourself. Order a door sample to examine the construction, finish, and style up close.
Size: 11" W x 15" H
Part Number: SAMPLE DOOR-SWD
Shipping: Free Shipping — refundable; apply up to 3 samples as credit toward order
Construction Details
Box Construction
Hardware
Style Details
Key Features
Dovetail Drawer Boxes
Drawer boxes are made from 5/8" rubberwood with hand-cut-style dovetail joints at all four corners.
Dovetail joinery distributes load across the joint rather than relying on fasteners alone, significantly extending service life under repeated daily use.
Birch Plywood Box Construction
Cabinet boxes are built from 1/2" birch plywood — no particle board or MDF used in the structural box.
Birch plywood holds screws reliably over time and resists moisture-induced swelling that degrades particle board in kitchen environments.
Solid Birch Face Frame
The face frame is 3/4" x 1-1/2" solid birch, providing a rigid front structure that ties the box together.
A solid wood face frame stiffens the box opening and creates a durable surface for hinge mounting and door alignment.
Soft-Close Hardware Throughout
Both door hinges and drawer glides are soft-close — doors and drawers decelerate before closing fully.
Concealed 6-way adjustable hinges allow post-installation door alignment correction in all directions without removing the door.
Quality Highlights
- 1/2" birch plywood box — no particle board in the structural cabinet
- 5/8" rubberwood drawer boxes with dovetail joinery
- Solid wood door frame with MDF center panel
- Soft-close undermount full-extension drawer glides
- 3/4" solid birch face frame
- Ships fully assembled in 7 business days or less
